Type: | Automatic Soda Filling Machine | Condition: | New |
---|---|---|---|
Product Name: | Automatic 3in1 Soda Water Filling Machinery Production Line | Warranty: | 2 Years |
Capacity: | 4000bph | Usage: | Filling Material |
Bottle Type: | PET Plastic Bottle | Processing Types: | Mineral |
Product Description
The carbonated drink filling machine used for prouction of PET bottle carbonated beverages (including alcoholic beverages), such as cola, alcoholic beverages, etc, the equipment has the function of cleaning filling, screw capping, it is availabe to a variety of bottle shape, and cusomter can choose different types according to customer's production .
Package : For round and squre bottles.
Capacity :From4000BPH-12000BPH (we also have high other mode for high capacity)
Product Features:
- The carbonated beverage filling machine adopts advanced PLC control and touch screen. Key electrical components come from internationally renowned brands .
- The machine adopts the advanced bottleneck clamping system to meet the requirement of bottle height. Therefore, when using different bottles on the same machine, only some parts need to be replaced.
- The material of equipment is stainless steel. Compact structure, beautiful appearance, reasonable design.
- It can be used for different bottles of 100ml to 3000ml bottles.
- Adopt the food grade stainless steel, avoid the secondary pollution that contact with bottle screw parts.
- The sealing head adopts the constant magnetic torque device to ensure the high quality and no damage. Efficient bottle cap precipitation system, bottle cap feeding system, no bottle cap system, make the whole sealing system perfect.
- The technology of direct contact with air conveyors replaces feeding screw and conveying device, making it more convenient to change the shape of the bottle.
Parameters
Model: | MT-CGF 18-18-6 | MT-CGF24-24-8 | MT-CGF32-32-12 | MT-CGF40-40-12 |
Production Capacity:600ml | 6000 | 8000 | 12000 | 16000 |
Suitable Bottle Standard: | round or square shaped bottle. | |||
Polyester Bottle Standard: (mm) | Bottle Diameter:ф60-ф110 Bottle Height:160-340 | |||
Suitable Cap Standard: | Plastic Screw Cap | |||
Filling Precision: | ≤±6mm | |||
Filling Pressure:(Mpa) | 0.16-0.36 | 0.16-0.36 | 0.16-0.36 | 0.16-0.36 |
Filling Pressure:(Mpa) | 0.2-0.26 | 0.2-0.26 | 0.2-0.26 | 0.2-0.26 |
Installed Capacity:(kw) | 3.6 | 4 | 6 | 8 |
Overall Size:(mm) | 2460×1800×2360 | 2780×2200×2360 | 3600×2660×2360 | 3800×2960×2400 |
Total Weight: (kg) | 3600 | 4600 | 6600 | 6600 |
Product Show
- years warranty for core parts of equipment.
- Free installation,debugging and training service will be provided after purchaes.
- trouble-shotting for life time maintanence.
if you need any help,please send us email for more details &vidoes"ations!
-
