Click the buttonSpring / Groundwater Drinking Water Production Line For Bottle 200 – 2000ml
The power of the screw cap be set according to requiremnt, t no bottle no filling, USES the frequency conversion technology, less electricity, can dynamically adjust speed.
The machine adopt normal pressure filling, the filling operation is much more faster and liquid level is precise and accurate,here is he details of machines.
Production capacity: 2000-28000bph(500ml)
We're here to help:Easy ways to get the answers you need.
Overview
| Type: | Drinking Water Filling Machine | Application: | Beverage |
|---|---|---|---|
| Packaging Type: | Bottles | Driven Type: | Electric |
| Voltage: | 220V/380V/Customization | Place Of Origin: | Shanghai, China (Mainland) |
| Brand Name: | Qualipak | Model Number: | MT32/32/10 |
| Dimension(L*W*H): | 3400*2600*2800mm | Weight: | 5000kg |
| Certification: | CE ISO SGS | Name: | Drinking Water Filling Machine/Turnkey Water Bottling Line |
| Capacity: | 15000BPH | Bottle Type: | PET Plastic Bottle/Glass Bottles |
| Bottle Size: | 200-2000ml | Machine Material: | Stainless Steel 304/316 |
| Control System: | Mitsubishi PLC+Touch Screen |
Automatic Spring /Ground Water Drinking Water Production Line Equipments For Bottle
Advantage
- The machine is used to produce mineral water, pure water, non-soda water.
- Collection cleaning, filling, rotating cover in one machine, reduce the area, save energy consumption.
- With the latest technology from Japan and Germany,
- while whole PLC control, it is highly automatic operation, when an error occurs the machine will automatic stop, use more secure,
- it can fill up to 38000 bottles per hour. Precise control of liquid volume, avoid dripping, it is able to set the cleaning time according to the requirement, the washing bottle is efficient, and the cleaning is much more cleaner than normal one.
- The power of the screw cap be set according to requiremnt, t no bottle no filling, USES the frequency conversion technology, less electricity, can dynamically adjust speed.
- The machine adopt normal pressure filling, the filling operation is much more faster and liquid level is precise and accurate,here is he details of machines.
- Production capacity: 2000-28000bph(500ml)
Specifications :
| Model | MT32-32-10 |
| Capacity(B/H) | 2000-28000 |
| Bottle size | Neck: φ 50-100mm Height: 150-320mm |
| Water pressure | 0.18-0.25Mpa |
| Water consumption(kg/h) | 3000 |
| Filling precision | +-2MM |
| Air pressure | 0.4Mpa |
| Air consumption | 0.8m³ /Hour |
| Power(kw) | 5 |
| Weight(kg) | 5000 |
| Dimension(L*W*H) | 3400*2600*2800mm |
Our Service
- What service do you offer in our company?
- Experienced staff member, quick and appropriate for your consultation
- Good installation, debugging, training and after-sales service
- We provide a 24 – month maintenance period for the replacement of the related parts free of charge due to our design, manufacturing and material quality problems
Contact us now !we will make business proposal for Free!
